30CrMnSiA Grade Drilling Pipe – High-Strength, Corrosion-Resistant & Weldable for Demanding Wells
Engineered for medium-high pressure, weakly corrosive, and dynamic-loading well environments, 30CrMnSiA grade drilling pipe delivers exceptional strength, corrosion resistance, and weldability — making it the reliable choice for challenging oilfield applications.
Key Features & Benefits
1. High Strength - Tensile strength ≥850 MPa – Outperforms standard carbon steels, ensuring reliable performance in high-pressure wells (35–50 MPa) and critical structural applications (e.g., deep casing).
2. Corrosion Resistance - 0.80–1.10% Chromium – Forms a protective oxide layer to resist brine, CO₂, and weakly acidic fluids, surpassing non-alloy carbon steels (e.g., 1541) in moderately corrosive environments (e.g., water injection wells, offshore fields).
3. Weldable Design - Low carbon equivalent (Ceq) – Enables low-preheat, post-weld heat treatment (PWHT)-free field welding, reducing downtime and simplifying on-site operations (e.g., casing connections, repairs).
4. Balanced Toughness - Elongation ≥14% – Absorbs dynamic loads (drill bit vibrations, pressure pulses), minimizing crack propagation and extending service life.
5. Lightweight & Efficient - Lighter than 4140 steel – Reduces tripping loads in deep/extended-reach wells without sacrificing strength.
Why 30CrMnSiA?
1. Better Than 1541 – Superior corrosion resistance for moderately corrosive wells (e.g., injection, offshore).
2. Cost-Effective Alternative to 4140/4130 – Delivers high strength (near 4130) and weldability at a lower alloy cost than premium grades (e.g., 4140).
3. Versatile Performance – Ideal for weld-intensive operations, dynamic-loading wells, and corrosion-sensitive environments.
Perfect for: Medium-high pressure wells, weakly corrosive formations, welding-heavy applications.
For extreme pressures, choose 4140; for shallow/budget wells, consider 1541.
Applications include fore poling (advance support), mine blasting, water well drilling, geothermal well drilling, and coal/nonferrous metal mining.
Chemical Composition
| Steel Grade | C | Si | Mn | P | S | Cr | Mo | B |
| 4130 | 0.28-0.33 | 0.15-0.35 | 0.40-0.60 | ≤0.040 | ≤0.040 | 0.80-1.10 | 0.15-0.25 | |
| 4140 | 0.38-0.43 | 0.15-0.35 | 0.75-1.00 | ≤0.040 | ≤0.040 | 0.80-1.10 | 0.15-0.25 | |
| 45MnMoB | 0.43-0.48 | 0.17-0.37 | 1.05-1.35 | ≤0.020 | ≤0.015 | | 0.20-0.25 | 0.001-0.005 |
| 1541 | 0.36-0.44 | - | 1.35-1.65 | ≤0.040 | ≤0.050 | | | |
| 30CrMnSiA | 0.28-0.34 | 0.90-1.20 | 0.80-1.10 | ≤0.020 | ≤0.015 | 0.80-1.10 | | |
Mechanical Properties
| Steel Grade | Deliver Condition | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | Hardness(HRC) |
| 4130 | + SR | ≥813 | ≥690 | ≥15% | ≥24 |
| 4140 | QT | ≥950 | ≥850 | ≥14% | 28 - 33 |
| 45MnMoB | + N | ≥790 | ≥600 | ≥14% | - |
| 1541 | + SR | ≥813 | ≥690 | ≥15% | ≥24 |
| 30CrMnSiA | QT | ≥850 | ≥750 | ≥14% | 26 - 31 |
Delivery Condition:
1. Stress Relief Annealing after Cold Working (+SR) (BKS)
2. Normalizing (+N) (NBK)
3. Quenching & Tempering (QT)
FAQ:
1. Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality.
You need to in charge of Express costs.
2. How about your production capacity?
3000 tons/Month.
3. What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.
4. Where is your factory?
Zhangjiagang city, 1.5 hours away from Shanghai.
5. How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
1). Tube Standard
2). Steel Grade
3). Tube Size and Size Tolerance
4). Tube length
5). Quantity
6). If any special requirements
6. How about the minimum order quantity?
Normally for one size above 1 ton.
Welcome to contact us! Thanks.
-
-
